ChordsStepper< T > Class Template Reference

The specialized Stepper to compute a step with the Chords Method (also called Secants in literature) More...

#include <stepper_def.hpp>

Inheritance diagram for ChordsStepper< T >:

Collaboration diagram for ChordsStepper< T >:

Public Member Functions
	ChordsStepper (std::function< double(double)> fun, bool aitken_mode, Eigen::Vector2d _int)
	Constructor for the ChordsStepper class.
Eigen::Vector2d	compute_step (Eigen::Vector2d previous_iteration) override
	Specialized method to compute and return a new step with Chords.
	ChordsStepper (std::function< double(double)> fun, bool aitken_mode, Eigen::Vector2d _int)
Eigen::Vector2d	compute_step (Eigen::Vector2d last_iter)
	Virtual function to compute the step for the method -> overridden by all the methods.
Public Member Functions inherited from StepperBase< T >
	StepperBase (std::function< double(double)> fun, bool aitken_mode)
	Constructor for virtual Stepper class, which will be inherited by the daughters.
virtual	~StepperBase ()=default
Eigen::Vector2d	step (Eigen::Vector2d previous_step)
	Method handling all the steps involved in computing the new guess.

Private Attributes
double	iter_minus_1
double	iter_zero
	The two previous guesses required at each iteration.

Additional Inherited Members
Protected Member Functions inherited from StepperBase< T >
Eigen::Vector2d	aitken_step (Eigen::Vector2d previous_iter)
	Method to handle the computation of a step using Aitken's acceleration.
Protected Attributes inherited from StepperBase< T >
std::function< double(double)>	function
	Function to compute the root of.
bool	aitken_requirement
	Option to use Aitken's acceleration.

Detailed Description

template<typename T>
class ChordsStepper< T >

The specialized Stepper to compute a step with the Chords Method (also called Secants in literature)

Constructor & Destructor Documentation

ChordsStepper() [1/2]

template<typename T >

ChordsStepper< T >::ChordsStepper	(	std::function< double(double)>	fun,
		bool	aitken_mode,
		Eigen::Vector2d	_int
	)

Constructor for the ChordsStepper class.

Parameters

fun	The function to compute the root of
aitken_mode	Option to use Aitken's acceleration
_int	2-dimensional vector storing the two initial guesses x(-1) and x(0)

ChordsStepper() [2/2]

ChordsStepper< Eigen::Vector2d >::ChordsStepper	(	std::function< double(double)>	fun,
		bool	aitken_mode,
		Eigen::Vector2d	_int
	)

Member Function Documentation

compute_step() [1/2]

Eigen::Vector2d ChordsStepper< Eigen::Vector2d >::compute_step ( Eigen::Vector2d  )

virtual

Virtual function to compute the step for the method -> overridden by all the methods.

Parameters

previous_iteration

2-dimensional vector storing x(i-1) and f(x(i-1)) - previous guesses

Returns

2-dimensional vector storing x(i) and f(x(i)) - new guesses

Implements StepperBase< T >.

compute_step() [2/2]

template<typename T >

Eigen::Vector2d ChordsStepper< T >::compute_step ( Eigen::Vector2d  previous_iteration )

overridevirtual

Specialized method to compute and return a new step with Chords.

After the computation, the two previous guesses are then updated for the next step.

Parameters

previous_iteration

2-dimensional vector storing x(i-1) and f(x(i-1)) - old guesses

Returns

2-dimensional vector storing x(i) = x(i-1) - (x(i-1) - x(i-2)) / (f(x(i-1)) - f(x(i-2))) * f(x(i-1)) and f(x(i)) - new guesses

Implements StepperBase< T >.

Member Data Documentation

iter_minus_1

template<typename T >

double ChordsStepper< T >::iter_minus_1

private

iter_zero

template<typename T >

double ChordsStepper< T >::iter_zero

private

The two previous guesses required at each iteration.

---

The documentation for this class was generated from the following file:

• libROOT/libROOT/stepper_def.hpp
